YBBP系列隔爆型变频调速三相异步电动机

YBBP series of explosion-proof frequency conversion speed control three phase asynchronous motor

YBBP系列隔爆型变频调速三相异步电动机适用于煤矿井下(非采掘工作面)及工厂含有爆炸性气体混合物的作业场所作电力拖动用,电动机与变频装置相配套,具有调速性能好、节能、温升裕度大、寿命长、性能好、噪音低、隔爆结构先进、可靠性高、使用维护方便等优点,通过改变频率而调速,电动机调速范围广,在开环U/f控制的条件下,3~50Hz恒转矩调速,50~100Hz为恒功率调速,在矢量控制的条件下,调速范围还可以扩大,过载能力强,能够承受额定转矩的160%过载,历时1min。 YBBP 变频调速三相异步电动机应用于轻工、纺织、化工、石油、冶金、机床、水泵等行业。YBBP系列电动机电气性后部增加独立冷动风机,YBBP系列隔爆型变频调速三相异步电动机安装尺寸与YB2系列电动机相同。 本系列电动机符合国家标准GB3836.1《爆炸性环境 第1部分:设备 通用要求》和GB3836.2《爆炸性环境 第2部分:由隔爆外壳“d”保护的设备 》的规定。电气性能符合JB/T 11201.1-2011《隔爆型变频调速三相异步电动机技术条件 第1部分:YBBP系列隔爆型变频调速三相异步电动机(机座号80~355)》的规定。 本系列电动机功率等级和安装尺寸符合国际电工委员会(IEC)标准。

YBBP series of explosion-proof frequency conversion speed contol three-phase asynchronous motor suitable for underground coal mines (non-excavation working face) and factory containing explosive gas mixtures for electric driving. The motor is matched with the frequency conversion device and has good speed regulation performance. Energy saving, large temperature rise margin, long life, excellent performance, low noise, advanced explosion-proof structure, high reliability, convenient installation and maintenance, etc. The speed is adjusted by changing the frequency, and the motor speed range is wide. In the open loop U/ Under f control conditions, 3~50Hz constant torque speed regulation, 50~100Hz constant power speed regulation, under vector control conditions, the speed regulation range can be expanded, overload capacity is strong, and it can withstand 160% of rated torque Overload, which lasted 1min. YBBP series of explosion-proof frequency conversion speed contol three-phase asynchronous motor is used in light industry, textile, chemical industry, petroleum, metallurgy, machine tool, water pump and other industries. YBBP series motors are equipped with independent cold-actuated fans at the back of their electrical properties. The installation dimensions of YBBP series of explosion-proof frequency conversion speed contol three-phase asynchronous motor are the same as those of YB2 series motors. This series of motors comply with the national standards GB3836.1 “Explosive Environment Part 1: General Requirements for Equipment” and GB3836.2 “Explosive Environment Part 2: Equipment Protected by Flameproof Enclosure “d””. The electrical performance meets the requirements of JB/T 11201.1-2011 “Technical Conditions of Flameproof Variable Frequency Adjustable Speed ​​Three-phase Asynchronous Motor Part 1: YBBP Series Flameproof Variable Frequency Adjustable Speed ​​Three-phase Asynchronous Motor (frame size 80-355)”. The power rating and installation dimensions of this series of motors comply with the International Electrotechnical Commission (IEC) standards.
